| Vertical Segment | : | Desktop |
| Processor Number | : | i3-8350K |
| Status | : | Launched |
| Lithography | : | 14 nm |
| Performance | : | |
| # of Cores | : | 4 |
| # of Threads | : | 4 |
| Processor Base Frequency | : | 4.00 GHz |
| Cache | : | 8 MB |
| Bus Speed | : | 8 GT/s DMI3 |
| TDP | : | 91 W |
| Supplemental Information | : | |
| Embedded Options Available | : | No |
| Conflict Free | : | Yes |
| Memory Specifications | : | |
| Max Memory Size (dependent on memory type) | : | 64 GB |
| Memory Types | : | DDR4-2400 |
| Max # of Memory Channels | : | 2 |
| ECC Memory Supported ‡ | : | No |
| Graphics Specifications | : | |
| Processor Graphics ‡ | : | Intel® UHD Graphics 630 |
| Graphics Base Frequency | : | 350 MHz |
| Graphics Max Dynamic Frequency | : | 1.15 GHz |
| Graphics Video Max Memory | : | 64 GB |
| Execution Units | : | 23 |
| 4K Support | : | Yes, at 60Hz |
| Max Resolution (HDMI 1.4)‡ | : | 4096x2304@24Hz |
| Max Resolution (DP)‡ | : | 4096x2304@60Hz |
| Max Resolution (eDP - Integrated Flat Panel)‡ | : | 4096x2304@60Hz |
| DirectX* Support | : | 12 |
| OpenGL* Support | : | 4.4 |
| Intel® Quick Sync Video | : | Yes |
| Intel® InTru™ 3D Technology | : | Yes |
| Intel® Clear Video HD Technology | : | Yes |
| Intel® Clear Video Technology | : | Yes |
| # of Displays Supported ‡ | : | 3 |
| Device | : | ID0x3E91 |
| Expansion Options | : | |
| Scalability | : | 1S Only |
| PCI Express Revision | : | 3 |
| PCI Express Configurations ‡ | : | Up to 1x16 or 2x8 or 1x8+2x4 |
| Max # of PCI Express Lanes | : | 16 |
| Package Specifications | : | |
| Sockets Supported | : | FCLGA1151 |
| Max CPU Configuration | : | 1 |
| Thermal Solution Specification | : | PCG 2015C (130W) |
| TJUNCTION | : | 100°C |
| Package Size | : | 37.5mm x 37.5mm |
| Low Halogen Options Available | : | See MDDS |
| Advanced Technologies | : | |
| Intel® Optane™ Memory Supported ‡ | : | Yes |
| Intel® Turbo Boost Technology ‡ | : | No |
| Intel® vPro™ Technology ‡ | : | No |
| Intel® Hyper-Threading Technology ‡ | : | No |
| Intel® Virtualization Technology (VT-x) ‡ | : | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d)‡ | : | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | : | Yes |
| Intel® TSX-NI | : | No |
| Intel® 64 ‡ | : | Yes |
| Instruction Set | : | 64-bit |
| Instruction Set Extensions | : | SSE4.1/4.2, AVX2 |
| Idle States | : | Yes |
| Enhanced Intel SpeedStep® Technology | : | Yes |
| Thermal Monitoring Technologies | : | Yes |
| Intel® Identity Protection Technology ‡ | : | Yes |
| Intel® Stable Image Platform Program (SIPP) | : | No |
| Security & Reliability | : | |
| Intel® AES New Instructions | : | Yes |
| Secure Key | : | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | : | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | : | Yes |
| Intel® OS Guard | : | Yes |
| Intel® Trusted Execution Technology ‡ | : | No |
| Execute Disable Bit ‡ | : | Yes |
| Intel® Boot Guard | : | Yes |
