| Essentials | ||
| Capacity | : | 512 GB |
| Status | : | Launched |
| Performance | ||
| Sequential Read (up to) | : | 1775 MB/s |
| Sequential Write (up to) | : | 560 MB/s |
| Random Read (8GB Span) (up to) | : | 128500 IOPS |
| Random Write (8GB Span) (up to) | : | 128000 IOPS |
| Power - Active | : | 100mW (Typical) |
| Power - Idle | : | 40mW (Typical) |
| Reliability | ||
| Vibration - Operating | : | 2.17 GRMS (5-700Hz) Max |
| Vibration - Non-Operating | : | 3.13 GRMS (5-800Hz) Max |
| Operating Temperature Range | : | 0°C to 70°C |
| Endurance Rating (Lifetime Writes) | : | 288 TBW |
| Mean Time Between Failures (MTBF) | : | 1.6 million hours |
| Uncorrectable Bit Error Rate (UBER) | : | <1> |
| Warranty Period | : | 5 yrs |
| Package Specifications | ||
| Form Factor | : | M.2 22 x 80mm |
| Interface | : | PCIe NVMe 3.0 x4 |
| Advanced Technologies | ||
| Enhanced Power Loss Data Protection | : | No |
| Hardware Encryption | : | AES 256 bit |
| –High Endurance Technology (HET) | : | No |
| Temperature Monitoring and Logging | : | No |
| End-to-End Data Protection | : | No |
| Intel® Smart Response Technology | : | Yes |
| Intel® Rapid Start Technology | : | Yes |
| Intel® Remote Secure Erase | : | No |
