| Status | : | Launched |
| Sequential Read | : | 560 MB/s |
| Sequential Write | : | 475 MB/s |
| Random Read (8GB Span) | : | 78000 IOPS |
| Random Write (8GB Span) | : | 85000 IOPS |
| Latency - Read | : | 50 µs |
| Latency - Write | : | 50 µs |
| Power - Active | : | 80 mW Typical |
| Power - Idle | : | 40 mW Typical |
| Vibration - Operating | : | 2.17 GRMS (5-700Hz) |
| Vibration - Non-Operating | : | 3.13 GRMS (5-800Hz) |
| Shock (Operating and Non-Operating) | : | 1000 G/0.5 ms |
| Operating Temperature Range | : | 0°C to 70°C |
| Mean Time Between Failures (MTBF) | : | 1.6 Million Hours |
| Uncorrectable Bit Error Rate (UBER) | : | <1> |
| Warranty Period | : | 5 yrs |
| Package Specifications | ||
| Capacity | : | 480 GB |
| Form Factor | : | M.2 22 x 80mm |
| Interface | : | SATA 3.0 6Gb/S |
| Lithography Type | : | 16nm |
| Advanced Technologies | ||
| Enhanced Power Loss Data Protection | : | No |
| Hardware Encryption | : | AES 256 bit |
| –High Endurance Technology (HET) | : | No |
| Temperature Monitoring and Logging | : | No |
| End-to-End Data Protection | : | No |
| Intel® Smart Response Technology | : | Yes |
| Intel® Rapid Start Technology | : | Yes |
