| Status | : | End of Life |
| Launch Date | : | Q4'15 |
| Expected Discontinuance | : | Q1'16 |
| EOL Announce | : | Tuesday, November 15, 2016 |
| Last Order | : | Monday, January 30, 2017 |
| Last Receipt Attributes | : | Monday, March 13, 2017 |
| Limited 3-year Warranty | : | Yes |
| Extended Warranty Available for Purchase (Select Countries) | : | Yes |
| # of QPI Links | : | 0 |
| Compatible Product Series | : | Intel® Xeon® Processor E3-1200 v5 Family |
| Board Form Factor | : | u ATX |
| Chassis Form Factor | : | Pedestal |
| Socket | : | 1 |
| Integrated Systems Available | : | No |
| Integrated BMC with IPMI | IPMI 2.0 | |
| TDP8 | : | 80 W |
| Included Items | : | (1) Server Board, (4) SATA Data Cables, (1) I/O Shield, (1) Attention Document; (1) Quick Start User’s Guide; (1) Quick Configuration Label |
| Supplemental Information | ||
| Embedded Options Available | : | No |
| Description | : | An entry-level single socket board with Intel® C232 chipset supporting one Intel® Xeon® Processor E3-1200 v5 family, 4 UDIMMs at up to 2133MHz and Dual integrated 1GBaseT Ethernet. |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | : | 64 GB |
| Memory Types | : | DDR4 ECC UDIMM |
| Max # of Memory Channels | : | 2 |
| Max Memory Bandwidth | : | 68.256 GB/s |
| Physical Address Extensions | : | 40-bit |
| Max # of DIMMs | : | 4 |
| ECC Memory Supported ‡ | : | Yes |
| DIMM Type | : | UDIMM |
| Graphics Specifications | ||
| Integrated Graphics ‡ | : | No |
| Graphics Output | : | VGA |
| Expansion Options | ||
| PCI Express Revision | : | 3 |
| Max # of PCI Express Lanes | : | 20 |
| PCIe x4 Gen | : | 31 |
| PCIe x8 Gen | : | 32 |
| I/O Specifications | ||
| # of USB Ports | : | 7 |
| USB Revision | : | 2,0&3,0 |
| Total # of SATA Ports | : | 6 |
| RAID Configuration | : | Software RAID RST (0,1,10,5) and ESRT2 (0,1,10) |
| # of Serial Ports | : | 1 |
| # of LAN Ports | : | 2 |
| Integrated LAN | : | 2x 1GbE |
| Embedded USB (eUSB) Solid State Drive Option | : | No |
| Integrated InfiniBand* | : | No |
| Package Specifications | ||
| Max CPU Configuration | : | 1 |
| Low Halogen Options Available | : | See MDDS |
| Advanced Technologies | ||
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | : | Yes |
| Intel® Node Manager | : | Yes |
| Intel® Rapid Storage Technology enterprise | : | Yes |
| Intel® I/O Acceleration Technology | : | Yes |
| Security & Reliability | ||
| Intel® Trusted Execution Technology ‡ | : | Yes |
