| Essentials | ||
| Status | : | Launched |
| Launch Date | : | Q2'13 |
| Limited 3-year Warranty | : | Yes |
| Extended Warranty Available for Purchase | : | Yes |
| # of QPI Links | : | 1 |
| Compatible Product Series | : | Intel® Xeon® processor E3-1200 v3 Product Family |
| Board Form Factor | : | uATX |
| Chassis Form Factor | : | 4U Rack or Pedestal |
| Socket | : | LGA1150 |
| Integrated Systems Available | : | Yes |
| Integrated BMC with IPMI | : | IPMI 2.0 |
| Rack-Friendly Board | : | Yes |
| Embedded Options Available | : | Yes |
| TDP | : | 95 W |
| Included Items | : | Intel® Server Board S1200V3RPL with (4) SATA Cables, (1) Intel® Server Deployment & Management DVD, (1) Attention document, and (1) Quick Start User’s Guide. |
| Board Chipset | : | Intel® C226 Chipset (Intel® DH82C226 PCH) |
| Description | : | An entry-level one socket board with Intel® C226 chipsetsupporting one Intel® Xeon® Processor E3-1200 family, 4 UDIMMs at up to 1600MHz and dual integrated Intel® Ethernet Controller. Optional mezzanine connector or Intel® Remote Management Module 4. |
| Target Market | : | Small Business/1st Server |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | : | 32 GB |
| Memory Types | : | DDR3 ECC UDIMM 1333, 1600 |
| # of Memory Channels | : | 2 |
| Max Memory Bandwidth | : | 25.6 GB/s |
| # of DIMMs | : | 4 |
| ECC Memory Supported ‡ | : | Yes |
| Graphics Specifications | ||
| Integrated Graphics ‡ | : | Yes |
| Graphics Output | : | VGA |
| Discrete Graphics | : | Supported |
| Expansion Options | ||
| PCI Express Revision | : | 3 |
| Max # of PCI Express Lanes | : | 16 |
| PCIe x8 Gen 3 | : | 1 |
| PCIe x1 Gen 2.x | : | 1 |
| PCIe x4 Gen 2.x | : | 1 |
| PCIe x8 Gen 2.x | : | 1 |
| Connector for Intel® I/O Expansion Module | : | 1 |
| Connector for Intel® Integrated RAID Module | : | 1 |
| I/O Specifications | ||
| USB Revision | : | 2.0 and 3.0 |
| # of USB Ports | : | 4 |
| Total # of SATA Ports | : | 6 |
| RAID Configuration | : | Software RAID RST (0,1,10,5) and ESRT2 (0,1,10) |
| # of Serial Ports | : | 1 |
| # of LAN Ports | : | 2 |
| Integrated LAN | : | 2x 1GbE |
| Firewire | : | No |
| Embedded USB (eUSB) Solid State Drive Option | : | Yes |
| Integrated SAS Ports | : | 0 |
| Integrated InfiniBand* | : | No |
| Package Specifications | ||
| Max CPU Configuration | : | 1 |
| Low Halogen Options Available | : | See MDDS |
| Advanced Technologies | ||
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | : | Yes |
| Intel® Remote Management Module Support | : | Yes |
| Intel® Node Manager | : | Yes |
| TPM Version | : | 1.2 |
| Intel® Quick Resume Technology | : | No |
| Intel® Quiet System Technology | : | No |
| Intel® Matrix Storage Technology | : | No |
| Intel® Rapid Storage Technology | : | No |
| Intel® Rapid Storage Technology enterprise | : | Yes |
| Intel® Fast Memory Access | : | Yes |
| Intel® Flex Memory Access | : | No |
| Intel® I/O Acceleration Technology | : | Yes |
| Intel® Advanced Management Technology | : | Yes |
| Intel® Server Customization Technology | : | No |
| Intel® Build Assurance Technology | : | No |
| Intel® Efficient Power Technology | : | No |
| Intel® Quiet Thermal Technology | : | No |
| Intel® Data Protection Technology | ||
| AES New Instructions | : | Yes |
| Intel® Platform Protection Technology | ||
| Trusted Execution Technology ‡ | : | Yes |
