| Essentials | ||
| Status | : | Launched |
| Launch Date | : | Q2'12 |
| Expected Discontinuance | : | 2015 |
| Limited 3-year Warranty | : | Yes |
| Extended Warranty Available for Purchase | : | Yes |
| # of QPI Links | : | 1 |
| Compatible Product Series | : | Intel® Xeon® Processor E5-2400 Product Family & Intel® Xeon® Processor E5-2400 v2 Product Family |
| Board Form Factor | : | SSI CEB 12" x 10.5" |
| Chassis Form Factor | : | 4U Rack or Pedestal |
| Socket | : | Socket B2 |
| Integrated Systems Available | : | Yes |
| Integrated BMC with IPMI | : | IPMI 2.0 |
| Rack-Friendly Board | : | Yes |
| Embedded Options Available | : | No |
| TDP | : | 95 W |
| Included Items | : | (1) Intel® Server Board S2400SC2, (1) I/O Shield, (4) SATA cables, (1) DVD contains Intel® Multi-Server Manager Software and Intel® Deployment Assistant, (1) Quick Start User Guide, and (1) Attention document. |
| Board Chipset | : | Intel® C602 Chipset (Intel® BD82C602 PCH) |
| Description | : | A value two socket server board for first server environments, supporting two Intel® Xeon® Processor E5-2400 family, eight DIMMs and 14 onboard SATA/SAS ports, expanded I/O with 33 total PCIe lanes including 28 PCI Gen3, and Intel® Server Management. |
| Target Market | : | Storage |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | : | 128 GB |
| Memory Types | : | DDR3 ECC UDIMM 1333, 1600/ RDIMM 1333,1600 |
| # of Memory Channels | : | 6 |
| Max Memory Bandwidth | : | 614.4 GB/s |
| Physical Address Extensions | : | 46-bit |
| # of DIMMs | : | 8 |
| ECC Memory Supported ‡ | : | Yes |
| Graphics Specifications | ||
| Integrated Graphics ‡ | : | Yes |
| Graphics Output | : | D-sub |
| Discrete Graphics | : | Supported |
| Expansion Options | ||
| PCI Express Revision | : | 3 |
| PCIe x4 Gen 3 | : | 1 |
| PCIe x8 Gen 3 | : | 1 |
| PCIe x16 Gen 3 | : | 1 |
| PCIe x4 Gen 2.x | : | 1 |
| I/O Specifications | ||
| USB Revision | : | 2 |
| # of USB Ports | : | 4 |
| Total # of SATA Ports | : | 6 |
| RAID Configuration | : | Software RAID ESRT2 (0,1,5,10) and RSTe (0,1,5,10) |
| # of Serial Ports | : | 2 |
| # of LAN Ports | : | 2 |
| Integrated LAN | : | 2x 1GbE |
| Firewire | : | No |
| Embedded USB (eUSB) Solid State Drive Option | : | Yes |
| Integrated SAS Ports | : | 0 |
| Integrated InfiniBand* | : | No |
| Package Specifications | ||
| Max CPU Configuration | : | 2 |
| Low Halogen Options Available | : | See MDDS |
| Advanced Technologies | ||
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | : | Yes |
| Intel® Remote Management Module Support | : | Yes |
| Intel® Node Manager | : | Yes |
| TPM Version | : | 1.2 |
| Intel® Quick Resume Technology | : | No |
| Intel® Quiet System Technology | : | No |
| Intel® HD Audio Technology | : | No |
| Intel® Matrix Storage Technology | : | No |
| Intel® Rapid Storage Technology | : | No |
| Intel® Rapid Storage Technology enterprise | : | Yes |
| Intel® Fast Memory Access | : | Yes |
| Intel® Flex Memory Access | : | Yes |
| Intel® I/O Acceleration Technology | : | Yes |
| Intel® Advanced Management Technology | : | Yes |
| Intel® Server Customization Technology | : | Yes |
| Intel® Build Assurance Technology | : | Yes |
| Intel® Efficient Power Technology | : | Yes |
| Intel® Quiet Thermal Technology | : | Yes |
| Intel® Data Protection Technology | ||
| AES New Instructions | : | Yes |
| Intel® Platform Protection Technology | ||
| Trusted Execution Technology ‡ | : | Yes |
