| Vertical Segment | : | Server |
| Processor Number | : | E5-2650V4 |
| Status | : | Launched |
| Launch Date | : | Q1'16 |
| Lithography | : | 14 nm |
| Performance | ||
| # of Cores | 12 | |
| # of Threads | : | 24 |
| Processor Base Frequency | : | 2.20 GHz |
| Max Turbo Frequency | : | 2.90 GHz |
| Cache | : | 30 MB SmartCache |
| Bus Speed | : | 9.6 GT/s QPI |
| # of QPI Links | : | 2 |
| TDP | : | 105 W |
| VID Voltage Range | : | 0 |
| Supplemental Information | ||
| Embedded Options Available | : | Yes |
| Conflict Free | : | Yes |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | : | 1.54 TB |
| Memory Types | : | DDR4 1600/1866/2133/2400 |
| Max # of Memory Channels | : | 4 |
| Max Memory Bandwidth | : | 76.8 GB/s |
| Physical Address Extensions | : | 46-bit |
| ECC Memory Supported ‡ | : | Yes |
| Expansion Options | ||
| Scalability | : | 2S |
| PCI Express Revision | : | 3 |
| PCI Express Configurations ‡ | : | x4, x8, x16 |
| Max # of PCI Express Lanes | : | 40 |
| Package Specifications | ||
| Sockets Supported | : | FCLGA2011-3 |
| Max CPU Configuration2 | : | 2 |
| TCASE | : | 80°C |
| Package Size | : | 45mm x 52.5mm |
| Low Halogen Options Available | : | See MDDS |
| Advanced Technologies | ||
| Intel® Turbo Boost Technology ‡ | : | 2 |
| Intel® vPro™ Technology ‡ | : | Yes |
| Intel® Hyper-Threading Technology ‡ | : | Yes |
| Intel® Virtualization Technology (VT-x) ‡ | : | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | : | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | : | Yes |
| Intel® TSX-NI | : | Yes |
| Intel® 64 ‡ | : | Yes |
| Instruction Set | : | 64-bit |
| Instruction Set Extensions | : | AVX 2,0 |
| Idle States | : | Yes |
| Enhanced Intel SpeedStep® Technology | : | Yes |
| Intel® Demand Based Switching | : | Yes |
| Thermal Monitoring Technologies | : | Yes |
| Intel® Flex Memory Access | : | No |
| Intel® Identity Protection Technology ‡ | : | No |
| Security & Reliability | ||
| Intel® AES New Instructions | : | Yes |
| Secure Key | : | Yes |
| Intel® OS Guard | : | Yes |
| Intel® Trusted Execution Technology ‡ | : | Yes |
