| Ordering P/N | TS-1231XU-RP-4G |
|---|---|
| Processor | AnnapurnaLabs, an Amazon company Alpine AL-314 Quad-Core 1.7 GHz ARM® Cortex-A15 CPU |
|
Hardware Encryption Accleration
|
yes |
| System Memory | 4GB DDR3 (1 x 4GB) |
| Maximum Memory | 16GB |
| Memory Slots | 2 x SODIMM DDR3 (Note: For dual-DIMM configurations, you must use a pair of identical DDR3 RAM modules.) |
| Flash Memory | 512MB |
| Drive Type | 12 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs |
| 10GbE LAN | 2 x 10 Gigabit SFP+ LAN ports |
| GbE LAN | 2 x Gigabit RJ45 LAN ports |
| USB | 4 x USB 3.0 ports |
| PCIe Slot | 1 x PCIe Gen2 (x2) |
| LED | Status/Power, LAN, HDD 1-12 |
| Button | Power, Reset |
| Other | Kensington security slot, console port |
| Dimension (HxWxD) | 89 x 482 x 534 mm 3.5 x 18.98 x 21.02 inch |
| Weight | Net: 11.41 kg(25.15 lbs) |
| Operating Temperature | 0-40C |
| Relative Humidity | 5~95% RH non-condensing, wet bulb: 27C |
| Noise Level | 47.6 dB(A) |
| Power Consumption | HDD standby: 48W In operation: 88.27W (with 12 x 2TB HDDs installed) |
| Power | ATX 250W, 100-240V AC, 5A-2.5A, 50Hz-60Hz (x2) |
| Fan | 2 x 7cm system fan (12V DC) |
