| CPU | AMD® G-Series GX-420MC quad-core 2.0 GHz processor |
|---|---|
|
Floating Point Unit
|
Yes |
|
Hardware Encryption Engine
|
Yes (AES-NI) |
| DRAM | System memory: TS-563-2G: 2GB DDR3L RAM (2GB x1)
Total memory slots: 2 SODIMMTS-563-8G: 8GB DDR3L RAM (8GB x1) Memory expandable up to: 16 GB (8GB x 2) NOTE: For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide |
| Flash Memory | 512MB |
| Hard Disk Drive | 5 x 3.5"or 2.5"SATA 6Gb/s, SATA 3Gb/s hard drive or SSD NOTE: 1. The system is shipped without HDD. 2. For the HDD compatibility list, please visit https://www.qnap.com/compatibility |
| Hard Disk Tray | 5 x Hot-swappable tray |
| LAN Port | 2 x Gigabit RJ-45 Ethernet port (Expandable up to 4 x GbE or 2 x 10GbE + 2 x GbE via PCIe NIC) |
| Network Expansion Slot | 1 (PCIe Gen2 x 4) |
| LED Indicators | Status, USB, HDD 1-5 |
| USB | 5 x USB 3.0 port (Front: 1, Rear: 4) Support USB printer, pen drive, and USB UPS etc. |
| Buttons | Power/Status, USB One-Touch-Backup, reset |
| Alarm Buzzer | System warning |
| Form Factor | Tower |
| Dimensions | 185(H) x 210.6(W) x 235.4(D) mm 7.28(H) x 8.29(W) x 9.27(D) inch |
| Weight | Net: 4.4 kg (9.7 lbs) Gross: 5.8 kg (12.79 lbs) |
| Power Consumption (W) | S3 sleep: 2.26W HDD standby: 30.17W In operation: 47.68W (with 5 x 2TB HDDs installed) |
| Sound Level* | Sound pressure (LpAm) :20.1 dB(A) |
| Temperature | 0-40?C |
| Humidity | 5~95% RH non-condensing, wet bulb: 27?C |
| Power Supply | ATX 250W, Input: 100V-240V ~ / 3.5A, 50Hz-60Hz |
| Secure Design | Kensington security slot for theft prevention |
| Fan | 1 x quiet cooling fan (12cm, 12V DC) |
