| CPU | Intel® Celeron® J3455 quad-core 1.5 GHz processor (burst up to 2.3 GHz) |
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Intel® HD Graphics 500 |
| Floating Point Unit | |
| Encryption Engine | (AES-NI) |
| System Memory | 4GB DDR3L (2 x 2 GB) |
| Maximum Memory | 8 GB (2 x 4GB) |
| Memory Slot | 2 x SO-DIMM DDR3L
When installing two memory modules, please ensure that they are the same size and ideally use the same type of RAM for both memory slots.
|
| Flash Memory | 4GB (Dual boot OS protection) |
| Drive Bay | 8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-swappable | |
| M.2 SSD Slot | Optional via a PCIe adapter |
| SSD Cache Acceleration Support | Drive bays 1 to 2 |
| Gigabit Ethernet Port (RJ45) | 4 |
| Jumbo Frame | |
| PCIe Slot | 1 Slot 1: PCIe Gen 2 x2 PCIe bandwidth limitations will restrict the NAS 10GbE performance.
|
| USB 3.0 port | 4 |
| USB 3.1 Gen 2 (10Gbps) Port | Optional via a PCIe adapter |
| HDMI Output | 1, HDMI 1.4b |
| Form Factor | 2U Rackmount |
| LED Indicators | HDD 1-8, Status, LAN, Expansion, Power |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 89 × 482 × 534 mm |
| Weight (Net) | 11.25 kg |
| Weight (Gross) | 14.88 kg |
| Operating temperature | 0 - 40 °C (32°F - 104°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27?C (80.6?F) |
| Power Supply Unit | ATX 250W (x2), Input: 100V-240V ~ / 5A-2.5A, 50Hz-60Hz |
| Power Consumption: HDD Sleep Mode | 40.5 W |
| Power Consumption: Operating Mode, Typical | 63.3 W
With drives fully populated
|
| Fan | 2 x 70mm, 12VDC |
| Sound Level | 31.6 db(A) |
| System Warning | Buzzer |
