| CPU | TVS-1271U-RP-PT-4G: Dual-core Intel® Pentium® G3250 3.1 GHz Processor TVS-1271U-RP-i3-8G: Dual-core Intel® Core™ i3-4150 3.5 GHz Processor TVS-1271U-RP-i5-16G: Quad-core Intel® Core™ i5-4590S 3.0 GHz Processor TVS-1271U-RP-i7-32G: Quad-core Intel® Core™ i7-4790S 3.2 GHz Processor |
|---|---|
| DRAM | TVS-1271U-RP-PT-4G
System memory: 4 GB DDR3 RAM
Memory module pre-installed: 2 GB x2 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) Note: When upgrading RAM to more than 20GB, the original 2GB RAM modules must be removed. TVS-1271U-RP-i3-8G: System memory: 8 GB DDR3 RAM
Memory module pre-installed: 4 GB x2 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) Note: When upgrading RAM to more than 24GB, the original 4GB RAM modules must be removed. TVS-1271U-RP-i5-16G: System memory: 16 GB DDR3 RAM
Memory module pre-installed: 8 GB x2 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) TVS-1271U-RP-i7-32G System memory: 32 GB DDR3 RAM
Memory module pre-installed: 8 GB x4 Total memory slots: 4 For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide |
| Flash Memory | 512MB DOM |
| Internal Cache Port | Two mSATA port on board for read caching Note: The standard system is shipped without mSATA flash module. For the optional mSATA flash module, please visit http://shop.qnap.com/ |
| Hard Drive | 12 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive or 2.5-inch SATA, SSD hard drive NOTE: 1. The standard system is shipped without hard drives. 2. For the hard drive compatibility list, please visit www.qnap.com/compatibility |
| Hard Disk Tray | 12 x hot-swappable and lockable tray |
| LAN Port | 4 x Gigabit RJ-45 Ethernet port (Expandable up to 8 x 1 Gb LAN or 4 x 10 Gb + 4 x 1 Gb LAN by installing optional dual-port 10 Gb and 1 Gb network card) Note: 1. For the optional network card compatibility list, please visit www.qnap.com/compatibility 2. For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual. |
| LED Indicators | Status, 10 GbE, LAN, storage expansion port status |
| USB/eSATA | 4x USB 3.0 port (rear) 4x USB 2.0 port (rear) Support USB printer, pen drive, USB hub, and USB UPS etc. |
| HDMI | 1 |
| Buttons | System: Power button and reset button |
| Alarm Buzzer | System warning |
| Form Factor | 2U, Rackmount |
| Dimensions | 89(H) x 482(W) x 534(D) mm 3.5(H) x 18.98(W) x 21.02(D) inch |
| Weight | 16.14 kg/ 35.58 lb (Net) 18.98 kg/ 41.84 lb (Gross) |
| Power Consumption (W) | HDD Standby: TVS-1271U-RP-PT-4G: 88.88
TVS-1271U-RP-i3-8G: 87.89 TVS-1271U-RP-i5-16G: 88.91 TVS-1271U-RP-i7-32G: 89.82 In Operation: TVS-1271U-RP-PT-4G: 173.38
TVS-1271U-RP-i3-8G: 176.27 TVS-1271U-RP-i5-16G: 174.64 TVS-1271U-RP-i7-32G: 176.42 (with 12 x WD WD20EFRX hard drive installed) |
| Sound Level* | Sound pressure (LpAm): 45.0 dB(A) |
| Temperature | 0~40?C |
| Relative Humidity | 5~95% non-condensing, wet bulb: 27?C. |
| Power Supply | Input : 100-240V~, 50-60Hz, 7A-3.5A Output: 500W |
| PCIe Slot | 2 (1* PCIe Gen3 x8, 1* PCIe Gen3 x4) |
| Fan | 3 x 7 cm smart cooling fan |
