| CPU | AMD G-series GX-424CC quad-core 2.4 GHz processor with Radeon™ graphics |
|---|---|
| DRAM |
TVS-863-4G: 4GB DDR3L-1600 x 1
TVS-863-8G: 8GB DDR3L-1600 x 1 Total memory slots: 2 Memory expandable up to: 16 GB (8GB x2) NOTE: For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide. |
| Flash Memory | 512MB DOM |
| Hard Disk Drive | 8 x 3.5”or 2.5”SATA 6Gb/s, SATA 3Gb/s hard drive or SSD NOTE: 1. The system is shipped without HDD. 2. For the HDD compatibility list, please visit https://www.qnap.com/compatibility/ |
| Hard Drive Tray | 8 x Hot-swappable tray |
| LAN Port | 2 x Gigabit RJ-45 Ethernet port (Onboard:2, expandable to max 4 ports via PCI-E NIC) |
| PCIe Slot | 1 (PCIe Gen2 x 4) |
| LCD Panel | Mono-LCD display with backlight, Enter and Select buttons for configuration |
| LED Indicators | Status, LAN, USB, HDD 1-8 |
| USB | 5 x USB 3.0 port (Front: 1, Rear: 4) Support USB printer, pen drive, and USB UPS etc. |
| HDMI | 2 (Mirrored Display), 1.4a Note: 4K video playback and transcoding are not supported |
| Buttons | Power/Status, USB One-Touch-Backup, reset |
| Alarm Buzzer | System warning |
| IR Receiver | QNAP RM-IR002 and MCE-compatible remotes |
| Form Factor | Tower |
| Dimensions | 185.2(H) x 298.2(W) x 235.4(D) mm 7.29(H) x 11.74(W) x 9.27(D) inch |
| Weight | Net:7.83 kg (17.26lbs) Gross: 8.9 kg (19.62lbs) |
| Power Consumption(W) | S3 sleep: 2.35W HDD standby: 46.21W In operation: 70.45W (with 8 x 2TB HDDs installed) |
| Sound Level* | Sound pressure (LpAm): 21.3 dB(A) |
| Temperature | 0-40?C |
| Humidity | 5~95% RH non-condensing, wet bulb: 27?C |
| Power Supply | ATX 250W, 110-240V AC, 50-60Hz, 5A |
| Secure Design | Kensington security slot for theft prevention |
| Fan | 2 x quiet cooling fan (12cm, 12V DC) |
