| CPU | TVS-871T-i5-16G: Quad-core Intel® Core™ i5-4590S 3.0GHz TVS-871T-i7-16G: Quad-core Intel® Core™ i7-4790S 3.2GHz |
|---|---|
|
Floating Point Unit
|
Yes |
|
Hardware Encryption Engine
|
Yes (AES-NI) |
| DRAM | System memory: 16 GB DDR3 RAM Memory module pre-installed: 8 GB x2 Total memory slots: 2 SODIMM |
| Flash Memory | 512MB DOM |
| Thunderbolt 2 Ports | 2 x Thunderbolt™ 2 high-speed ports |
| Hard Drive | 8 x 3.5"or 2.5" SATA 6Gb/s, SATA 3Gb/s hard drive or SSD NOTE:
|
| Hard Disk Tray | 8 x hot-swappable tray |
| LAN Port | 2 x 10 Gigabit Ethernet port (10GBased-T) 4 x 1 Gigabit Ethernet port |
| LED Indicators | Status, USB, LAN, HDDs |
| USB | 3 x USB 3.0 port ( front: 1, rear: 2) 2 x USB 2.0 port (rear) Support USB printer, pen drive, USB hub, and USB UPS etc. |
| HDMI | 1 |
| Buttons | Power, USB One-touch-copy backup, Reset |
| Alarm Buzzer | System warning |
| Form Factor | Tower |
| Dimensions | 185.2 (H) x 298.2 (W) x 235.4 (D) mm 7.29 (H) x 11.74 (W) x 9.27 (D) inch |
| Weight | 7.83 kg/ 17.26 lbs (Net) 8.9 kg/ 19.62 lbs (Gross) |
| Power Consumption (W) | TVS-871T-i5-16G:HDD Standby: 45.43 TVS-871T-i7-16G: HDD Standby: 45.37 (with 8 x WD WD20EFRX hard drive installed) |
| Sound Level* | Sound pressure (LpAm): 23.1 dB(A) |
| Temperature | 0~40?C |
| Relative Humidity | 5~95% non-condensing, wet bulb: 27?C. |
| Power Supply | ATX Input: 100-240V AC, 50/60Hz Output: 350W |
| PCIe Slot | 2 (1* PCIe Gen3 x8, 1* PCIe Gen2 x4) Note: 2 PCle slots are occupied by a Thunderbolt 2 card and a 10GbE adapter |
| Fan | 2 x quiet cooling fan (12 cm, 12V DC) |
