| Essentials | ||
| StatusL | : | Launched |
| Launch Date | : | Q1'16 |
| Expected Discontinuance | : | Q4'19 |
| Limited 3-year Warranty | : | Yes |
| Extended Warranty Available for Purchase (Select Countries) | : | Yes |
| # of QPI Links | : | 2 |
| Compatible Product Series | : | Intel® Xeon® Processor E5-2600 v4 Family |
| Board Form Factor | : | SSI EEB 12" x 13" |
| Chassis Form Factor | : | Rack or Pedestal |
| Socket | : | Socket R3 |
| Integrated Systems Available | : | No |
| Integrated BMC with IPMI | : | IPMI 2.0 with OEM extensions |
| Rack-Friendly Board | : | Yes |
| TDP | : | 145 W |
| Included Items | : | (1) Intel® Server Board S2600CW2R; (1) I/O shield; (2) SATA cables; (1) Quick Start User’s Guide; (1) Attention document and configuration labels. Note: the OEM 10 Pack does not ship with included items. |
| Target Market | : | Embedded |
| Supplemental Information | ||
| Embedded Options Available | : | No |
| Description | : | A general purpose server board supporting two Intel® Xeon® processor E5-2600 V3/V4 family up to 145W, 16 DIMMs, and two 1-Gb ethernet ports |
| Memory Specifications | ||
| Max Memory Size (dependent on memory type) | : | 1.02 TB |
| Memory Types | : | DDR4 ECC RDIMM/LRDIMM 1600/1866/2133/2400 |
| Max # of Memory Channels | : | 8 |
| Max Memory Bandwidth | : | 153.6 GB/s |
| Physical Address Extensions | : | 46-bit |
| Max # of DIMMs | : | 16 |
| ECC Memory Supported ‡ | : | Yes |
| Graphics Specifications | ||
| Integrated Graphics ‡ | : | Yes |
| Graphics Output | : | VGA |
| Discrete Graphics | : | Supported |
| Expansion Options | ||
| PCI Express Revision | : | 3 |
| Max # of PCI Express Lanes | : | 84 |
| PCIe x8 Gen | : | 31 |
| PCIe x16 Gen | : | 34 |
| PCIe x4 Gen 2.x | : | 1 |
| I/O Specifications | ||
| # of USB Ports | : | 7 |
| USB Revision | : | 2.0 & 3.0 |
| Total # of SATA Ports | : | 10 |
| RAID Configuration | : | PCH SATA 6G ESRT2 RAID 0,1,10 |
| # of Serial Ports | : | 1 |
| # of LAN Ports | : | 2 |
| Integrated LAN | : | 2x 1GbE |
| Firewire | : | No |
| Embedded USB (eUSB) Solid State Drive Option | : | Yes |
| Integrated SAS Ports | : | 0 |
| Integrated InfiniBand* | : | No |
| Package Specifications | ||
| Max CPU Configuration | : | 2 |
| Low Halogen Options Available | : | See MDDS |
| Advanced Technologies | ||
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes | : | Yes |
| Intel® Remote Management Module SupportYes | : | Yes |
| Intel® Node ManagerYes | : | Yes |
| Intel® Quick Resume TechnologyNo | : | No |
| Intel® Quiet System TechnologyNo | : | No |
| Intel® HD Audio TechnologyNo | : | No |
| Intel® Matrix Storage TechnologyNo | : | No |
| Intel® Rapid Storage TechnologyNo | : | No |
| Intel® Rapid Storage Technology enterpriseYes | : | Yes |
| Intel® Fast Memory AccessYes | : | Yes |
| Intel® Flex Memory AccessYes | : | Yes |
| Intel® I/O Acceleration TechnologyYes | : | Yes |
| Intel® Advanced Management TechnologyYes | : | Yes |
| Intel® Server Customization TechnologyYes | : | Yes |
| Intel® Build Assurance TechnologyYes | : | Yes |
| Intel® Efficient Power TechnologyYes | : | Yes |
| Intel® Quiet Thermal TechnologyYes | : | Yes |
| Intel® Transparent Supply Chain | ||
| TPM Version1.2 | : | 1,2 |
| Security & Reliability | ||
| Intel® AES New InstructionsYes | : | Yes |
| Intel® Trusted Execution Technology ‡Yes | : | Yes |
